Use trackBy in Angular ngFor Loops and MatTables

A missing trackBy in an ngFor block or a data table can often result in hard-to-track and seemingly glitchy behaviors in your web app. Today, I’ll discuss the signs that you need to use trackBy. But first—some context:

More often than not, you’ll want to render some repeated element in Angular. You’ll see code that looks like this:

<ng-container *ngFor="let taskItem of getTasks(category)">

In cases where the ngFor is looping over the results of a function that are created anew each time (e.g. an array being constructed using .map and .filter), you’ll run into some issues.

Every time the template is re-rendered, a new array is created with new elements. While newly-created array elements might be equivalent to the previous ones, Angular uses strict equality on each element to determine how to handle it.

In cases where the elements are an object type, strict equality will show that each element of the array is new. This means that a re-render would have a few side-effects:

  • Angular determines all the old elements are no longer a part of the block, and
    • destroys their components recursively,
    • unsubscribes from all Observables accessed through an | async pipe from within the ngFor body.
  • Angular finds newly-added elements, and
    • creates their components from scratch,
    • subscribing to new Observables (i.e. by making a new HTTP request) to each Observable it accesses via an | async pipe.

This also leads to a bunch of state being lost:

  • selection state inside the ngFor is lost on re-render,
  • state like a link being in focus, or a text-box having filled-in values, would go away.
  • if you have side-effects in your Observable pipes, you’ll see those happen again.

The Solution

trackBy gives you the ability to define custom equality operators for the values you’re looping over. This allows Angular to better track insertions, deletions, and reordering of elements and components within an ngFor block.

Categories
Software

About those Side-effects in Observables, an Angular Use Case

When testing a codebase in Angular Ivy, I ran into a bunch of test failures I wasn’t seeing before. ExpressionChangedAfterItHasBeenCheckedErrors were being thrown around. In debugging these failures, I found that many of them are the results of side-effects in Observables and Observable pipe operations. I happened to describe these earlier in my piece on Observables, Side-effects, and Subscriptions.

Consider this minimal reproduction:

@Component({
  selector: 'widget-editor',
  templateUrl: 'widget_editor.html'
})
export class WidgetEditor {
  constructor(private readonly service: WidgetService) {}

  widgetName = '';
  widgetConfig$ = this.service.getWidget('my_widget').pipe(
    map(widgetDetails => {
      this.widgetName = widgetDetails.name;
      return widgetDetails.config;
    })
  );
}
Categories
Software

Data and Page Content Refresh patterns in Angular

Part of why I recommend using RxJS Observables all the way through in Angular TypeScript code, and only unpacking them at the closest point to where the UI is declared (often using the | async pipe), is because it makes other transformations on an Observable available and convenient. Two such examples include retry and refresh logic.

Two common reasons to reload/refresh data being displayed by a component include:

  1. A user action in the application causes the data to change (especially, if it does so in ways that might result in complex state changes, etc.), and/or
  2. The data being displayed can change over time (e.g. due to a progression/change of it’s state in the backend, or by another user, etc.)

Let’s start with a simple example:

@Component({
  selector: 'task',
  template: `<ng-container *ngIf="(task$ | async) as task">
    <h1>{{task.name}}</h1>
    <p>Status: {{task.status}}</p>
    <sub-task *ngFor="let subTask of task.subtasks" [subTask]="subTask"/>`
})
export class TaskComponent {
  constructor(private readonly http: HttpClient) {}
  readonly task$ = this.http.get('/api/tasks/foo');
}

Suppose the user adds a ‘Mark as Complete’ button, that mutates the server-side state of all sub-tasks. How do obtain the latest authoritative data from the server about the state of our side? Here’s an approach:

export class TaskComponent {
  constructor(private readonly http: HttpClient) {}

  private readonly refreshToken$ = new BehaviorSubject(undefined);
  private readonly task$ = this.refreshToken$.pipe(
    switchMap(() => this.http.get('/api/tasks/foo')));

  markAsComplete() {
    this.http.post('/api/tasks/foo', { state: State.Done })
      // N.B. contrary to my advice elsewhere, I'm happy to
      // directly subscribe here because this subscribe
      // callback has side effects.
      // Further, I don't worry about unsubscribing since
      // this returned Observable is a one-shot observable
      // that will complete after a single request.
      .subscribe(() => this.refreshToken$.next(undefined));
  }
}

Adding refresh logic this way will minimally affect our template code and looks relatively clean. Better yet, adding additional mutating functions simply need to call refreshToken$.next to make sure new data is loaded.

What about regularly polling for updates? This can be implemented simply as well:

export class TaskComponent {
  constructor(private readonly http: HttpClient) {}

  private readonly autoRefresh$ =
    interval(TASK_REFRESH_INTERVAL_MS)
      .pipe(startWith(0));

  private readonly refreshToken$ = new BehaviorSubject(undefined);

  private readonly task$ =
    // Notice that combineLatest will only trigger the first
    // time when an event triggers on all input Observables
    // you are combining.
    // BehaviorSubject always triggers its latest value when
    // you subscribe to it, so we're good there.
    // An interval() Observable will need a 'startWith' to
    // give you an initial event.
    combineLatest(this.autoRefresh$, this.refreshToken$)
    .pipe(
      switchMap(() => this.http.get('/api/tasks/foo'))
    );

  markAsComplete() {
    this.http.post('/api/tasks/foo', { state: State.Done })
      .subscribe(() => this.refreshToken$.next(undefined));
  }
}

What if we didn’t want to hardcode foo as the task we look up? Well, Angular’s ActivatedRoute already uses Observables. Rather than using route.snapshot.params['task_id'] or similar, we can use the actual Observable results and get our minds off manually refreshing that data:

Categories
Software

Use AsyncPipe When Possible

I typically review a fair amount of Angular code at work. One thing I typically encourage is using plain Observables in an Angular Component, and using AsyncPipe (foo | async) from the template html to handle subscription, rather than directly subscribing to an observable in a component TS file.

Subscribing in Components

Unless you know a subscription you’re starting in a component is very finite (e.g. an HTTP request with no retry logic, etc), subscriptions you make in a Component must:

  1. Be closed, stopped, or cancelled when exiting a component (e.g. when navigating away from a page),
  2. Only be opened (subscribed) when a component is actually loaded/visible (i.e. in ngOnInit rather than in a constructor).

Consider:

@Component()
 export class Foo
   implements OnInit, OnDestroy {

   someStringToDisplay = '';
   private readonly onDestroy =
     new ReplaySubject<void>(1);

   ngOnInit() {
     someObservable.pipe(
       takeUntil(this.onDestroy),
       map( ... ),
     ).subscribe(next => {
       this.someStringToDisplay = next;
       this.ref.markForCheck();
     });
   }

   ngOnDestroy() {
     this.onDestroy.next(undefined);
   }
 }
@Component()
 export class Foo
   implements OnInit, OnDestroy {

   someStringToDisplay = '';
   private subscription =
     Subscription.EMPTY;

   ngOnInit() {
     this.subscription = someObservable.pipe(
       map( ... ),
     ).subscribe(next => {
       this.someStringToDisplay = next;
       this.ref.markForCheck();
     });
   }

   ngOnDestroy() {
     this.subscription.unsubscribe();
   }
 }
<span>{{someStringToDisplay}}</span>

AsyncPipe can take care of that for you

@Component() export class Foo {
   someStringToDisplay = someObservable.pipe(
     map(...),
   );
 }
<span>{{someStringToDisplay | async}}</span>

Much better! No need to remember to manage unsubscribe. No need to implement OnDestroyAsyncPipe does its own unsubscribe on destruction, etc. If you only implement OnInit to make a new subscription, you can forego that too.

Best Practice: Use publishReplay and refCount if accessing the same Observable from multiple places

If you need to access a value multiple times, consider using the publishReplay and refCount RxJS operators:

readonly pageTitle = this.route.params.pipe(
   map(params => params['id']),
   flatMap(id => this.http.get(
     `api/pages/${id}/title`,
     {'responseType': 'text'})),
   publishReplay(1),
   refCount()
);
<h1>{{pageTitle | async}}</h1>
<p>You are viewing {{pageTitle | async}}.</p>

This will cause the template rendering to make a single request for pageTitle, and cache the result between both uses.

Best Practice: Combine *ngIf, as, and else with AsyncPipe

If you need to handle the loading state, and need to display nested properties of an object returned from an observable, you can do something like:

<ng-container *ngIf="(pageObservable | async) as page; else loading">
   <!-- can refer to 'page' here -->
   <h1>{{page.title}}</h1>
   <p>{{page.paragraph}}</p>
 </ng-container>
 <ng-template #loading>Loading…</ng-template>

Note that this doesn’t distinguish between the case where pageObservable is still loading, and the case where pageObservable resolved to a falsey value.
