Server Environments

Adapted from photo by wocintechCC BY 2.0

When maintaining large software systems, you will likely have multiple environments with names like Prod, Staging, Dev, Eval, UAT, Daily, Nightly, or some remix of these names. To distinguish this type of environment from the dozen other things in software development that we give that same name, these are often formally referred to as Deployment Environments.

One question I’ve never been asked directly is: “What is an Environment?” This is surprising; because not understanding what Deployment Environments actually are is one of the most common pitfalls I see in my day-to-day work.

What is a Deployment Environment

A Deployment Environment is a consistently connected set of

  1. processes
  2. datastores, and
  3. any ecosystem around them (e.g., cron jobs, analytics, etc.)1

making up a fully functioning software system.

This definition is quite intuitive, but the devil is in the details. In this case, that detail is the phrase “consistently connected”.

What consistently connected entails

Ideally, environments should be perfectly isolated; no data or RPC should leak between processes and data stores across environments during normal operation2.

A Case Study

This concrete example convinces the uninitiated that you should never mix dependencies across environments (e.g., Dev instances should only call other Dev instances; never prod instances). If this is already intuitive for you, you can skip this section and go straight to the principles of consistent connectedness.

An Architecture Diagram representing a simple To-do system. An HTTP endpoint calls TodoApi and PeopleApi. Todo API is connected to a database called TodoStore, while PeopleApi is connected to some People graph service called PeopleStore. There's also a ReminderService that reads TodoStore and sends push notifications to the HTTP endpoint. The user communicates only with the HTTP endpoint via a browser.

An architecture representing a To-do system with some interdependencies.

Imagine the architecture above represents a system you maintain. Each box here represents either a service or a datastore. Right now, you have one instance of each of these endpoints, and they’re connected as you see above. Let’s say these systems are connected by directly addressing each other (e.g., by calling specific URIs for each service). Real people are about to use this service, but you want to continue deploying more recent versions.

You might decide to create a set of Dev instances to help you out.

You might wonder: How many instances do I need to set up and configure to have a viable Dev environment?

What is viable will certainly depend on which endpoints you care about testing.

Let’s assume you want to test TodoApi. This service:

  • Calls PeopleApi
  • Reads and writes to TodoStore
  • Is called by PeopleApi
  • Is called by HttpBackend

Generally, if you can exercise the service you’re interested in directly, you might not care about its callers.

Next, you have to decide:

  • which PeopleApi should this instance call, and
  • which TodoStore should this instance read and write to?

Remember that PeopleApi will call TodoApi back. It’s very tough (and almost always wrong) to try to get away with calling the Production instance of PeopleApi from your Dev instance of TodoApi; the production instance you call might mutate the production state, or it might call back the production instance of TodoApi instead of you. You might convince yourself it’s harmless, but more often than not, you’ll be met with subtle glitchy behavior at best and serious bugs or user data leaks at worst.

Instead, you’ll want an entirely separate Dev instance of PeopleApi in its own right. As you configure this dev instance of PeopleApi, you will have only one correct choice for which TodoApi to call: the Dev instance we just created.

We will also likely want a separate TodoStore database to be available to the Dev instance of TodoApi, with totally separate tasks, etc. This allows us to make sure none of our read/write testing has the potential to affect production users.

This line of reasoning applies recursively and can help you arrive at some general principles.

Principles of consistent connectedness

An instance of a service or datastore can be described as being in an environment. An instance can be in exactly one environment, and we can usually identify a specific instance by what environment it is in. If an architecture diagram includes a TodoService, we can refer to instances of that service as “TodoService Prod”, “TodoService Dev”, etc.

Given this, for any environment Env, an instance is in Env if and only if:

  • it is only called by other instances in Env,
  • it only calls instances in Env, and
  • the instances it calls are equivalent in topology to the architecture diagram of Production (or a strict subset).

These principles of course have their limits if you stretch the definitions of words like process and call. For example, as long as you have good addressing separation, your distinct environments do not need to live on non-overlapping servers or live in separate clouds. Other core infrastructure might also be exempt if it has strong environment separation and does not need to have separate testing instances brought up often.

What you shouldn’t do with a Deployment Environment

To maintain a valid environment, there are a few things you shouldn’t do (that plenty of people do):

  • Decide that a given instance in some environment actually makes more sense to call another instance in another environment.

    Trust me, 99.99% of the time, it isn’t.

    You might tell yourself, for example: “Oh but the Dev instance doesn’t have interesting data”; “my Dev instance should call the Prod photo catalog service!”.

    You’re almost always better off doing something else, like seeding fake photos in the Dev photo catalog instance and continuing to call that, or setting up a cron job that copies over photos from the prod catalog to the dev catalog, after making sure they’re stripped of any sensitive data, etc.

    You might convince yourself none of the pitfalls apply today (“the Prod service I’m calling is stateless”; “the Prod service I’m calling is a sink”), but it’s often hard to guarantee this will always be the case. Exercise plenty of caution when you are forced to do this.

  • Treat an instance of a service you own that exists in some environment as “internal to your team”.

    If you have a Dev environment, in your company, and your team maintains the TodoService, you might consider saying “TodoService Dev is for our team only, no one else should call it”. This will often break consistent connectedness, however.

    Other teams’ Dev instances should call your Dev instance. Your Dev instance should do the same.

    If you want an internal service only you can call, it should be totally sandboxed. You will of course run into trouble if your instance has dependencies that can’t be stubbed out since your sandboxed instance might violate consistent connectedness if it writes to other teams’ Dev datastores.

The challenge with maintaining valid environments

The challenge, for many, in maintaining a valid, consistently connected environment is addressing.

Addressing, in this context, describes how a given instance describes which other instance it is going to interact with (i.e., services to call, pubsub channels to broadcast to or listen from, databases to read from or write to).

Services, databases, and pubsub channels might identify themselves with nothing but an IP and port, a full URI, a process ID, or some other naming and addressing scheme.

Each service must have a way to address all of its dependencies, either written in its configuration, passed into it through command-line flags, encoded in the binary, etc.

If the addressing and configuration scheme in a given setup is brittle, then so will the topology and health of the deployment environments. For example, service that identifies its dependencies by an arbitrary host and port (say, [::1]:8001 for PeopleApi and [::1]:8002 for its TodoStore) in command-line flags is very easy to contain mistakes. That service will also have trouble programmatically verifying that it is correctly connected.

A smaller organization might get away with a slightly more brittle addressing scheme than a larger organization. When stretching the brittleness to the extreme (e.g., hosts and ports passed by hand to command-line flags), however, even the smallest organizations will have trouble keeping healthy environment separation.

While some enjoy the flexibility of configuration setups where we can individually pick and choose what each dependency address should be, internalizing the importance of consistent connectedness will help us notice that this approach is often more brittle than powerful.

Approaches to Consistent Connectedness

Endpoint Registries

Can we restructure and centralize our configuration into a registry? Rather than a client specifying the address of the instance it wants, it provides an (Environment, Service) pair (e.g., ("dev", "TodoService")) to a registry that is responsible for returning the correct address.

Such registries can be built into binaries, libraries that themselves consume registry data that is pushed regularly, or simply middleware layers that abstract away brittle configuration.

Relative URI Addressing Schemes

If instances can address each other via a URI, we can invert the concept of an Endpoint Registry to our benefit.

Rather than services that accept traffic on a host and port, we can set our services up to accept traffic at a specific path. We can then set up a server that accepts traffic to a hostname for an environment and routes the traffic to the individual services in that environment.

We can have services like /_/api/TodoService and /_/api/PeopleService. In Dev, we have a hostname like dev-todoapp.acme.com that serves these paths through the Dev instances.

In this case, we can have

  • todoapp.acme.com (Production)
    • todoapp.acme.com/_/api/TodoService
    • todoapp.acme.com/_/api/PeopleService
  • dev-todoapp.acme.com (Development)
    • dev-todoapp.acme.com/_/api/TodoService
    • dev-todoapp.acme.com/_/api/PeopleService

In this case, services can address each other through hostname-relative URIs. TodoService can address PeopleService in its code by /_/api/PeopleService.

Smash the Topology with Data-Oriented Architecture

Other architectures, like Data-Oriented Architecture, allow us to ditch complicated topologies in favor of routing all interactions through a Data Access Layer monolith.

A typical microservices architecture
Data-oriented architecture

Because all process-to-process interaction in Data-Oriented Architecture goes through a Data Access Layer (DAL), an environment is effectively defined by which data layer it talks to.

A TodoService writing Todo objects into a DAL and querying People objects will always be dealing with consistent data.

A TodoService that addresses the Prod DAL is writing & reading Prod Todos and is querying Prod People. A PeopleService talking to that DAL is necessarily the Prod instance! Without loss of generality, we can say the same about services talking to the Dev DAL, and so on.

A Better Definition of Environment

So far, I’ve described deployment environments that are 1:1 with the datastores that make up the system. However, if your system architecture allows you to have multiple replicated services talking to the same data store, you might wonder to what extent is the data store isolation important.

One way to add nuance to our definition of a deployment environment is to also define Storage Environment as a distinct concept.

A Storage Environment is a consistently connected set of datastores that represent the state of the world according to that environment.

For a consumer product, there will typically be a single production storage environment, and more internal (fake, test, dev) storage environments for testing. For business-facing products, each customer’s “production” environment can be its own storage environment.

Armed with the definition of a storage environment, a Deployment Environment can be defined as a consistently connected set of processes & an ecosystem that agree on a storage environment.

Typically, a consistently connected set of processes would share some property in common. For instance, mature builds can make up a production environment, while cutting-edge builds might make up a development environment.

For example, imagine a company that has two Storage Environments:

  1. public
  2. testing

and uses those to create a few environments:

  1. Production (public storage environment with release binaries & schemas)
  2. Staging or RC (public storage environment with rc binaries & schemas)
  3. Nightly (public storage environment with fresh binaries & schemas)
  4. QA (testing storage environment with rc binaries & schemas)
  5. Development (testing storage environment with fresh binaries & schemas)

While each instance in a deployment environment must agree on the storage environment it is in, you’d be forgiven to wonder whether consistent connectedness within a deployment environment is as important as it was under the old definition.

Consistent connectedness is certainly not as crucial in this definition. For example, you might decide that Nightly in the definition above is more useful if each instance (in the public storage environment) with fresh binaries is calling the production binaries. A common motivation for this is to isolate bugs to a specific service, i.e. you don’t want a bug in PeopleService to make it look like TodoService is also broken.

In practice, though, especially because many dependency and call graphs can be quite circular, it’s actually hard to isolate the effects of a broken service that way. For example, if Nightly services called Production services, it is unclear if a break in the nightly TodoService would manifest in a failure in TodoService, rather than one in the Production PeopleService, as a result of a malformed payload/call from the Nightly TodoService.

If you have no such cycles in your architecture diagram, such schemes might work for you, but my general recommendation is to continue value consistent connectedness for its simplicity.

What about Sandboxes?

Sandboxes are typically isolated sub-sets of an architecture of a given system. If a Sandbox is truly isolated, it can be an excellent way to test a given service, with the immediate dependencies that concern it.

Some architectures lend themselves well to sandboxing (e.g., Data-Oriented Architecture) where missing components simply stub out parts of some functionality but never break an active call chain. Other architectures might rely on stub implementations to achieve the desired result.

Often still, however, many sandboxes will leak out in the edges to a real long-running environment. In that case, it is important to think carefully about what is and isn’t a valid sandbox construction.

A few pointers can help:

  • Just like an instance of a service or datastore, a Sandbox itself can be said to be in a particular environment
  • If an architecture diagram includes a cycle, that entire cycle should be either inside or outside of the Sandbox, in other words, an instance in a Sandbox should not try to call an instance that won’t call (transitively?) call it back
  • A sandbox should leak to at most one environment; in other words: the edges of the sandbox that are communicating with real instances must all communicate to instances in the same environment
  • Production is almost always the wrong environment to leak a sandbox into, but will often be the most tempting.

Closing Thoughts

I don’t think anyone ever asked me “What is an environment?” Yet I’ve certainly found myself arguing against configurations of large systems that effectively cross and break environments. Terms as ubiquitous as “environment” often feel obvious at first glance, but not too much more.

Here, I tried to give a strongly-worded view of how an environment can be defined. Rules are meant to be broken, and I’ve broken all of these rules (to mixed results). So my goal isn’t to tell you, dear reader, the One True Way, but rather, to communicate an ideal that, if we veer away from, we do so consciously.


  1. I include the rest of the ecosystem around this for completeness, but often it’s sufficient to think of a Deployment Environment simply as a consistently connected set of processes & datastores.

  2. Explicit processes that exist beyond the bounds of any environment may purposely interact with multiple environments. For example, it might be desirable to sync or seed some test data between environments, etc.
